Go: What is Flags Enum and How to Implement It

In C#, a flags enum lets you mix multiple enum values using bitwise operations, it's a unique form of enum.

Photo by Matt Brown on Unsplash

The [Flags] attribute in C# signals that you can treat an enum as either a set of flags or a bit field. For example:

[Flags]
enum TextFormats {
    Bold = 1,
    Italic = 2,
    Underline = 4
}

Go, on the other hand, doesn’t have built-in support for this type of enum. If you want similar features in Go, you’ll have to use bitwise operations and something called iota to make your own flags enum.

---

How flag enum works?

If flag enums are old news to you, feel free to jump ahead.

Let’s break down how this actually operates, using the earlier example for context:

[Flags]
enum TextFormats {
    Bold = 1, // 001
    Italic = 2, // 010
    Underline = 4 // 100
}

In this specific example, the value attributed to Bold is 1, which in binary format is 0001. Similarly, Italic has been assigned the number 2, corresponding to 0010 in binary, and Underline is designated with 4, equivalent to 0100 in binary.

If we combine the Bold and Italic enums using the ‘|’ operator and when you do that, the outcome would be Bold | Italic, resulting in a binary value of 011 and a decimal value of 3 (derived from 2⁰+ 2¹).

To sum up: Bold is represented by the number 1, Italic by 2, and the combination of Bold and Italic gives you 3. It’s an intuitive way to handle multiple options, thanks to bitwise operations.

However, be cautious that adding more keys to your enum will escalate the values quickly.

Flags Enum In Go

In Go, we can use the iota keyword together with the shift left operator to mimic the behavior of a flags enum:

const (
  Bold      = 1 << iota // 1 (001)
  Italic                // 2 (010)
  Underline             // 4 (100)
)

func main() {
  formatTypes := Bold | Italic
  fmt.Println(formatTypes) // 3 (011)
}

“Is that all there is to it?”

No, let’s also add utility functions that make the flags enum easier to handle:

• Has(flags int, value int): Checks if a particular value is present within the flags, “Does the format variable have the Bold value set?”

func Has(set, flag int) bool {
  return set&flag == flag
}

• Add(flags int, value int): Adds a given value to the flags enum, similar to the example above.

func Add(flags int, value int) int {
  return flags | value
}

• Remove(flags int, value int): Deletes a specific value from the flags enum. If you’re new to bitwise operations, this might require some getting used to.

func Remove(flags int, value int) int {
    return flags &^ value
}

“What about method chaining like text.Has(Bold), text.Add(Bold), text.Remove(Italic)?”

We’ll cover that in the next section, where we’ll be building our own bitwise toolset.

Getting a Handle on Flags Enum

So, we’re going to establish a new type called ‘Bitwise’ and shift those global functions to become methods for this new type, here’s what it looks like:

type Bitwise int

func (set Bitwise) Has(flag Bitwise) bool {
  return set&flag == flag
}

func (set Bitwise) Remove(flag Bitwise) Bitwise {
  return set &^ flag
}

func (set Bitwise) Add(flag Bitwise) Bitwise {
  return set | flag
}

With this structure, you can use the methods in a chain-like manner:

func main() {
  formatTypes := Underline | Italic
  formatTypes = formatTypes.Add(Bold).Remove(Underline)
  fmt.Println(formatTypes) // 3: Bold | Italic
}

And one more thing, if you’re not keen on crafting your own simple toolkit, the math/bits package in Go can help simplify these bitwise operations

---
